SPECS
GENERAL
• Chipset Type
Intel Z590
• Compatible Processors
(supports 11th and 10th Generation Intel Core / Pentium Gold / Celeron)
• Processor Socket
LGA1200 Socket
• Max Processors Qty
1
• Manufacturer
MSI Computer Corp.
EXPANSION / CONNECTIVITY
• Expansion Slots
1 x CPU
4 x DIMM 288-pin
2 x PCIe 4.0 x16 (dual x8 mode; single card: x16 mode)
1 x PCIe 3.0 x16 (x4 mode)
2 x PCIe 3.0 x1
• Storage Interfaces
SATA-600 -connectors: 6 x 7pin Serial ATA – RAID 0 / RAID 1 / RAID 10 / RAID 5
SATA-600 / PCIe 3.0 -connectors: 2 x M.2 – RAID 0 / RAID 1
PCIe 4.0 -connectors: 1 x M.2
• Internal Interfaces
4 x USB 2.0 – header
2 x USB 3.2 Gen 1 – header
1 x USB-C Gen2 – header
1 x audio – header
• Power Connectors
24-pin main power connector, 8-pin ATX12V connector, 6-pin PCI Express power connector
• RAID Features
Intel Smart Response Technology
PROCESSOR
• Max Supported Qty
1
• Installed Qty
0
INTERFACE PROVIDED
• Qty
1, 2, 3, 4
• Type
DisplayPort, HDMI, TOSLINK, USB 2.0, audio line-in, audio line-out, audio line-out (center/subwoofer), audio line-out (rear), microphone
• Connector Type
mini-jack
NETWORKING
• Data Link Protocol
2.5 Gigabit Ethernet, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
PROCESSOR / MEMORY / STORAGE
• Max Supported Qty
1
MISCELLANEOUS
• Product Type
motherboard
• Included Accessories
3 x M.2 screws, cable labels, case badge
AUDIO
• Audio Codec
Realtek ALC4080
• Compliant Standards
High Definition Audio
VIDEO
• Video Output
graphics adapter (CPU required)
AUDIO OUTPUT
• Compliant Standards
High Definition Audio
• Type
sound card
• Audio
High Definition Audio (8-channel)
RAM
• Features
Intel Extreme Memory Profiles (XMP), dual channel memory architecture
LAN
• Network Interfaces
2.5 Gigabit Ethernet, 802.11a/b/g/n/ac/ax, Bluetooth 5.2
• Network Controller
Intel I225-V / Intel AX210
SUPPORTED RAM
• Bus Clock
2133 MHz, 2666 MHz, 2933 MHz, 4000 MHz (O.C.), 4400 MHz (O.C.), 4700 MHz (O.C.), 3200 MHz, 5333 MHz (O.C.)
• Features
Dual channel memory architecture, Intel Extreme Memory Profiles (XMP)
• Registered or Buffered
Unbuffered
• Technology
DDR4
• Max Size
128 GB
• Supported RAM Integrity Check
Non-ECC
HEADER
• Brand
MSI
• Product Line
MSI
• Packaged Quantity
1
MAINBOARD
• Form Factor
ATX
• Supported RAM Technology
DDR4 SDRAM
• Supported RAM Speed
2133 MHz, 2666 MHz, 2933 MHz, 4000 MHz (O.C.), 4400 MHz (O.C.)
• Supported RAM Integrity Check
non-ECC
• Supported RAM (Registered or Buffered)
unbuffered
• RAM Slots
4 DIMM slots
• Power Connectors
24-pin main power connector, 6-pin PCI Express power connector, 8-pin ATX12V connector
MAINBOARD FEATURES
• BIOS Features
MSI ClickBIOS 5
• Hardware Features
AMD 3-way CrossFireX technology support, Intel Optane Memory Ready, M.2 Shield FROZR, MSI Core Boost, MSI Mystic Light, MSI Steel Armor, pre-mounted I/O shield
INTERFACES
• Storage
M.2 socket, Serial ATA-600 (RAID)
• Storage Ports
6 x SATA-600 (RAID), 3 x M.2
• RAID Features
Intel Smart Response Technology
• USB 3.0 / FireWire
USB-C Gen2
CABLE DETAILS
• Type
Serial ATA cable
• Included Qty
2
EXPANSION SLOTS
• Total Qty
1, 2, 4
• Slot Comments
dual x8 mode; single card: x16 mode, x4 mode
• Type
CPU, DIMM 288-pin, PCIe 3.0 x1, PCIe 3.0 x16
DIMENSIONS & WEIGHT
• Width
12 in
• Depth
9.6 in
STORAGE INTERFACES
• Interface
Serial ATA-600, Serial ATA-600 / PCIe 3.0
• Connector(s)
1 x M.2, 2 x M.2, 6 x 7pin Serial ATA
• RAID (Level)
RAID 0 / RAID 1
INTERNAL INTERFACES
• Type
USB 2.0, USB-C Gen2, audio
• Connector Type
header
• Qty
1, 2, 4
FEATURES
• Hardware Features
AMD 3-way CrossFireX technology support, MSI Mystic Light, MSI Steel Armor, Intel Optane Memory Ready, M.2 Shield FROZR, pre-mounted I/O shield, MSI Core Boost, 16+1+1 Phase Power Design, MSI Audio Boost 5
• BIOS Features
MSI ClickBIOS 5
GENERAL
• Manufacturer
MSI Computer Corp.
